Ordering information

           Accessories

           The following accessories are available for
           SNL housings in the 30, 31 and 32 series:

           •  Oil leveller: LAHD
           •  Automatic lubricators: SKF SYSTEM 24 or
            SKF MultiPoint. If frequent relubrication is
            required and SKF SYSTEM 24 is to be used,
            combine it with LAPM 4 (Manifold 4 to 1).                                   5
           •  Grease meter: LAGM 1000E
           •  Condition monitoring sensors
           For additional information, refer to SKF tools
           and products († page 47).

           Ordering information

           For SNL housings in the 30, 31 and 32 series,
           each of the following items must be ordered
           separately:
           •  housing
           •  seals
           •  end cover
           •  locating rings
           •  bearing
           •  adapter sleeve

           Order example
           Two plummer block housings with labyrinth
           seals are required for two 23036 CCK/W33
           bearings on H 3036 adapter sleeves. One
           housing will accommodate the non-locating
           bearing at the end of the shaft. The other
           housings will accommodate the locating
             bearing and a through shaft.
            The following items should be ordered (in
           addition to the bearings and adapter sleeves):
           •  2 housings SNL 3036
           •  3 labyrinth seals TS 36
           •  1 end cover ETS 36
           •  2 locating rings FRB 17/280
