Lubrication

Table 10b
Recommended oil levels 1)
Housing Shaft Design and bearing series
Size diameter TURT TURA
231 222 223 C 31 C 22
min. max. min. max. min. max. min. max. min. max.
– mm mm
SNL 3134 115 55 66
150 50 56 48 58 5
SNL 3136 125 58 69
160 52 59 49 61
SNL 3138 135 59 71
160 53 64
170 54 61 48 61
SNL 3140 140 71 84
170 65 77 64 80
180 65 74 60 73
SNL 3144 200 62 71 56 70
SNL 3148 170 75 91
200 69 84
220 68 78 64 81 67 90
SNL 3152 220 70 87
240 72 83 65 83
SNL 3156 200 87 106
260 81 93 74 92
SNL 3160 220 90 112
260 81 102
280 85 98 78 98
SNL 3164 240 93 116
280 83 107
300 89 103 84 108
SNL 3168 260 96 121
300 85 112
320 93 108 84 110
SNL 3172 340 90 106 84 110
SNL 3176 360 91 108 87 111
SNL 3180 340 98 124
380 99 116 88 111
SNL 3184 400 108 128 103 129
SNL 3188 410 106 125 106 133
SNL 3192 430 109 130 103 131
SNL 3196 450 116 137 112 139

1) The oil level is measured from the base of the housing. Mark the min and max level on the oil level gauge.
