Gewindefräser · Thread Milling Cutters GF-Z
Product Mit höherer Nutenzahl
Finder 60° With increased number of fl utes
M, MF
P
v / f VHM
z
c
M
DIN 13 R15 RH + LH
MF
UNC Z6 DIN 6535
UN, UNS HB
HE
UNF HA
UNEF Für Innengewinde
For internal threads ø D
G, Rp
Z
NPT, NPTF
Rc, W
ø d 1 ø d 2
BSW, BSF
l 2 l 3
Pg l 1
EG (STI) P 1.1- 5.1 K 1.1- 4.2 N 1.1-5, 2.1-6
SELF-LOCK Einsatzgebiete – Material  328
Applications – material N 3.1-2 N 4.1-2, 5.2 S 1.1-3
Tr
GF-Z-VHM GF-Z-VHM GF-Z-VHM
P ø D min. ø d 1 R15-IKZ-HB R15-IKZ-HE R15-IKZ-HA
Zubehör mm mm mm ø d l l l Z
Accessories 2 1 2 3
1 14 9,9 10 70 20,4 40 6 GF165361.9512 GF165661.9512 GF165961.9512
Tech. Info 1,5 16 11,9 12 80 26,1 45 6 GF165371.9514 GF165671.9514 GF165971.9514
2 22 15,9 16 90 32,9 48 6 GF165381.9516 GF165681.9516 GF165981.9516
3 30 19,9 20 105 43,3 50 6 GF165391.9518 GF165691.9518 GF165991.9518
BGF
ZBGF
TICN
GSF
GF
GF-KEG
ZGF
Einsatzgebiete – Material  328 P 1.1- 5.1 M 1.1- 4.1 K 1.1- 4.2
ZIRK-GF Applications – material N 1.1- 5.2 S 1.1- 2.6 H 1.1-2

Gigant GF-Z-VHM GF-Z-VHM GF-Z-VHM
P ø D min. ø d 1 R15-IKZ-HB R15-IKZ-HE R15-IKZ-HA
mm mm mm ø d l l l Z TICN TICN TICN
MoSys 2 1 2 3
1 14 9,9 10 70 20,4 40 6 GF165366.9512 GF165666.9512 GF165966.9512
1,5 16 11,9 12 80 26,1 45 6 GF165376.9514 GF165676.9514 GF165976.9514
2 22 15,9 16 90 32,9 48 6 GF165386.9516 GF165686.9516 GF165986.9516
3 30 19,9 20 105 43,3 50 6 GF165396.9518 GF165696.9518 GF165996.9518
Andere Steigungen auf Anfrage
Tools for different thread pitch upon request

386 Bestell-Beispiel · Ordering example: GF165361.9512
