Gewindefräser · Thread Milling Cutters GF
Product
Finder 60°
LK-M
P
v / f VHM
c
z
M BT
EMUGE-Norm · EMUGE Standard RH + LH
MF
UNC Z4 - Z5 DIN 6535
UN, UNS HB
HE
UNF HA
UNEF Für Innengewinde
For internal threads ø D
G, Rp
Z
NPT, NPTF
Rc, W
ø d 1 ø d 2
BSW, BSF
l 2 l 3
Pg l 1
EG (STI) P 1.1- 5.1 K 1.1- 4.2 N 1.1-5, 2.1-6
SELF-LOCK Einsatzgebiete – Material  328
Applications – material N 3.1-2 N 4.1-2, 5.2 S 1.1-3
Tr
GF-VHM GF-VHM GF-VHM
P ø D min. ø d 1 IKZ-HB IKZ-HE IKZ-HA
Zubehör mm mm mm ø d l l l Z
Accessories 2 1 2 3
1 14 9,9 10 70 16,4 40 4 GF163211.9757 GF163511.9757 GF163811.9757
Tech. Info 1 16 11,9 12 80 20,4 45 4 GF163121.9757 GF163421.9757 GF163721.9757
1,5 14 9,9 10 70 17 40 4 GF163211.9664 GF163511.9664 GF163811.9664
1,5 16 11,9 12 80 21,5 45 4 GF163121.9664 GF163421.9664 GF163721.9664
BGF 2 22 15,9 16 90 26,7 48 5 GF163131.9705 GF163431.9705 GF163731.9705
3 30 19,9 20 105 34,1 50 5 GF163151.9767 GF163451.9767 GF163751.9767
ZBGF
GSF
TICN
GF
GF-KEG
ZGF
ZIRK-GF
Einsatzgebiete – Material  328 P 1.1- 5.1 M 1.1- 4.1 K 1.1- 4.2
Gigant Applications – material N 1.1- 5.2 S 1.1- 2.6 H 1.1-2
GF-VHM GF-VHM GF-VHM
MoSys
P ø D min. ø d 1 IKZ-HB IKZ-HE IKZ-HA
mm mm mm ø d 2 l 1 l 2 l 3 Z TICN TICN TICN
1 14 9,9 10 70 16,4 40 4 GF163216.9757 GF163516.9757 GF163816.9757
1 16 11,9 12 80 20,4 45 4 GF163126.9757 GF163426.9757 GF163726.9757
1,5 14 9,9 10 70 17 40 4 GF163216.9664 GF163516.9664 GF163816.9664
1,5 16 11,9 12 80 21,5 45 4 GF163126.9664 GF163426.9664 GF163726.9664
2 22 15,9 16 90 26,7 48 5 GF163136.9705 GF163436.9705 GF163736.9705
3 30 19,9 20 105 34,1 50 5 GF163156.9767 GF163456.9767 GF163756.9767
Andere Steigungen auf Anfrage
Tools for different thread pitch upon request

398 Bestell-Beispiel · Ordering example: GF163211.9757
