Gewindefräser · Thread Milling Cutters GF
Product
Finder 55°
G (BSP), Rp (BSPP), W
P
v / f VHM
c
z
M
DIN EN ISO 228, DIN EN 10226-1, ISO 7/1, BS 84 R30 RH + LH
MF
UNC Z4 - Z5 DIN 6535
UN, UNS HB
HE
UNF HA
UNEF Für Innen- und Außengewinde
For internal and external threads ø D ø D
G, Rp
Z
NPT, NPTF
Rc, W
ø d 1 ø d 2
BSW, BSF
l 2 l 3
Pg l 1
EG (STI) P 1.1- 3.1 K 1.1- 4.2 N 1.1-5
SELF-LOCK Einsatzgebiete – Material  328
Applications – material N 2.1-6 N 3.1- 4.2, 5.2 S 1.1-2
Tr
GF-VHM GF-VHM GF-VHM
P ø D min. 1) ø d 1 R30-IKZ-HB R30-IKZ-HE R30-IKZ-HA
Zubehör Gg/1" (tpi) inch mm ø d l l l Z
Accessories 2 1 2 3
19 1 /4 9,9 10 70 16,7 40 4 GF162211.9545 GF162511.9545 GF162811.9545
Tech. Info 14 1 /2 11,9 12 80 20,9 45 4 GF162121.9548 GF162421.9548 GF162721.9548
14 1 /2 15,9 16 90 26,3 48 5 GF162131.9548 GF162431.9548 GF162731.9548
14 3 /4 19,9 20 105 33,5 50 5 GF162151.9548 GF162451.9548 GF162751.9548
BGF 11 1" 15,9 16 90 26,5 48 5 GF162131.9550 GF162431.9550 GF162731.9550
11 1" 19,9 20 105 33,5 50 5 GF162151.9550 GF162451.9550 GF162751.9550
ZBGF
GSF
TICN
GF
GF-KEG
ZGF
ZIRK-GF
Einsatzgebiete – Material  328 P 1.1- 3.1 M 1.1- 2.1 K 1.1- 4.2
Gigant Applications – material N 1.1- 2.7 N 3.1- 5.2 S 1.1-2, 2.1
GF-VHM GF-VHM GF-VHM
MoSys 1)
P ø D min. ø d 1 R30-IKZ-HB R30-IKZ-HE R30-IKZ-HA
Gg/1" (tpi) inch mm ø d 2 l 1 l 2 l 3 Z TICN TICN TICN
19 1 /4 9,9 10 70 16,7 40 4 GF162216.9545 GF162516.9545 GF162816.9545
14 1 /2 11,9 12 80 20,9 45 4 GF162126.9548 GF162426.9548 GF162726.9548
14 1 /2 15,9 16 90 26,3 48 5 GF162136.9548 GF162436.9548 GF162736.9548
14 3 /4 19,9 20 105 33,5 50 5 GF162156.9548 GF162456.9548 GF162756.9548
11 1" 15,9 16 90 26,5 48 5 GF162136.9550 GF162436.9550 GF162736.9550
11 1" 19,9 20 105 33,5 50 5 GF162156.9550 GF162456.9550 GF162756.9550
1) Durchmesser bezogen auf Rohr-Innengewinde bzw. Rohr-Außengewinde
Diameter related to internal pipe thread resp. external pipe thread

394 Bestell-Beispiel · Ordering example: GF162211.9545
