Gewindefräser · Thread Milling Cutters GF-Z

Mit höherer Nutenzahl Product
55° VHM With increased number of fl utes Finder
P
G (BSP), Rp (BSPP), W v / f z
c
DIN EN ISO 228, DIN EN 10226-1, ISO 7/1, BS 84 R15 RH + LH new new new M
MF
Z5 - Z8 DIN 6535 UNC
HB UN, UNS
HE
HA UNF
Für Innengewinde UNEF
For internal threads ø D ø D
G, Rp
Z
NPT, NPTF
Rc, W
ø d 1 ø d 2
BSW, BSF
l 2 l 3
l 1 Pg
EG (STI)
Einsatzgebiete – Material  328 P 1.1- 5.1 K 1.1- 4.2 N 1.1-5, 2.1-6 SELF-LOCK
Applications – material N 3.1-2 N 4.1-2, 5.2 S 1.1-3
Tr
GF-Z-VHM GF-Z-VHM GF-Z-VHM
P ø D min. ø d 1 R15-IKZ-HB R15-IKZ-HE R15-IKZ-HA
mm mm mm ø d 2 l 1 l 2 l 3 Z Zubehör
Accessories
1
19 G /4 9,9 10 70 20,7 40 6 GF165361.9545 GF165661.9545 GF165961.9545
1
14 G /2 11,9 12 80 26,3 45 5 GF165371.9548 GF165671.9548 GF165971.9548 Tech. Info
1
14 G /2 15,9 16 90 33,6 48 6 GF165381.9548 GF165681.9548 GF165981.9548
3
14 G /4 19,9 20 105 40,8 50 8 GF165391.9548 GF165691.9548 GF165991.9548
11 G 1" 15,9 16 90 33,5 48 5 GF165381.9550 GF165681.9550 GF165981.9550 BGF
11 G 1" 19,9 20 105 42,7 50 6 GF165391.9550 GF165691.9550 GF165991.9550
ZBGF
new new new GSF
TICN
GF
GF-KEG
ZGF
ZIRK-GF
Einsatzgebiete – Material  328 P 1.1- 5.1 M 1.1- 4.1 K 1.1- 4.2
Applications – material N 1.1- 5.2 S 1.1- 2.6 H 1.1-2 Gigant
GF-Z-VHM GF-Z-VHM GF-Z-VHM
P ø D min. ø d 1 R15-IKZ-HB R15-IKZ-HE R15-IKZ-HA MoSys
mm mm mm ø d 2 l 1 l 2 l 3 Z TICN TICN TICN
1
19 G /4 9,9 10 70 20,7 40 6 GF165366.9545 GF165666.9545 GF165966.9545
1
14 G /2 11,9 12 80 26,3 45 5 GF165376.9548 GF165676.9548 GF165976.9548
1
14 G /2 15,9 16 90 33,6 48 6 GF165386.9548 GF165686.9548 GF165986.9548
3
14 G /4 19,9 20 105 40,8 50 8 GF165396.9548 GF165696.9548 GF165996.9548
11 G 1" 15,9 16 90 33,5 48 5 GF165386.9550 GF165686.9550 GF165986.9550
11 G 1" 19,9 20 105 42,7 50 6 GF165396.9550 GF165696.9550 GF165996.9550
Andere Steigungen auf Anfrage
Tools for different thread pitch upon request

Spannzangen-Aufnahmen Collet holders
Typ KSN/Synchro type KSN/Synchro,
siehe Seite 711 - 713 see page 711 - 713

= Lagerwerkzeug, siehe Preisliste · Stock tool, see price list 395
= Kurzfristig lieferbar, Preis auf Anfrage · Available on short notice, price upon inquiry
