Insert bearings (Y-bearings)

2 Insert bearings (Y-bearings)

2

Designs and variants 341 Mounting and dismounting 359
Insert bearings with grub screws 342 Assembling insert bearings into housings with itting
Basic design bearings 342 slots 362
Bearings with zinc-coated rings 342 SKF ConCentra insert bearings 363
Stainless steel bearings 342
Insert bearings with an eccentric locking collar 343 Designation system 364
SKF ConCentra insert bearings 344
Insert bearings with a tapered bore 344 Product tables
Insert bearings with a standard inner ring 345 2.1 Insert bearings with grub screws, metric shafts 366
Sealing solutions 345 2.2 Insert bearings with grub screws, inch shafts 368
Standard seals 345 2.3 Insert bearings with an eccentric locking collar,
Standard seals with additional lingers 345 metric shafts 372
Multiple seals 346 2.4 Insert bearings with an eccentric locking collar,
5-lip seals 346 inch shafts 374
RS1 seals 346 2.5 SKF ConCentra insert bearings, metric shafts 376
Shields 346 2.6 SKF ConCentra insert bearings, inch shafts 377
Cages 347 2.7 Insert bearings with a tapered bore on an adapter
Rubber seating rings 347 sleeve, metric shafts 378
2.8 Insert bearings with a tapered bore on an adapter
Lubrication 348 sleeve, inch shafts 379
Greases for capped bearings 348 2.9 Insert bearings with a standard inner ring, metric
Grease life for insert bearings 348 shafts 380
Relubrication 348

Bearing data 350
(Dimension standards, tolerances, radial internal
clearance, permissible misalignment)

Loads 353
(Minimum load, axial load carrying capacity, equivalent
dynamic bearing load, equivalent static bearing load)

Temperature limits 355
Other insert bearings (Y-bearings)
Permissible speed 355 High temperature bearings 1005
Bearings with Solid Oil 1023
Design considerations 356 Bearings with a customized design or customized
Axial displacement 356 dimensions → contact SKF
Shaft tolerances 358 Ball bearing units (Y-bearing units) → skf com/bearings
