Maschinen-Gewindebohrer · Machine Taps Enorm 2
Product Z SPEED
Finder 60° DIN CNC-controlled High-speed
M
P
cutting
machines
v c 376
M
DIN 13
MF
UNC
UN-8
UNF
UNEF
G, Rp
NPSM, NPSF
NPT, NPTF l 1
Rc, W
l 2
BSW, BSF
ø d 1 ø d 2
Pg
MJ Toleranz · Tolerance
UNJC, UNJF ISO 3/6G 6HX 6HX 6H +0,1 2) 6HX 6HX 6HX 6HX 6HX 6HX 6HX 6HX
Beschichtung · Coating TIN TIN TICN TICN TICN TICN TIN-70 TIN-70 TIN-60 TIN-60
EG (STI)
SELF-LOCK Technische Informationen Schneidstoff · Cutting material HSSE HSSE HSSE HSSE HSSE HSSE HSSE HSSE HSSE-PM HSSE-PM HSSE-PM HSSE-PM
Tr, Tr-F Technical information  245 - 266 R45 R50 R50 R50 R45 R45
Rd
E / 1,5-2 C / 2-3 C / 2-3 C / 2-3 C / 2-3 C / 2-3 E / 1,5-2 E / 1,5-2 B / 4-5 B / 4-5 C / 2-3 C / 2-3
Zubehör E / O / P E / O / P E / O / P E / O / P E E E E E E E E
Accessories
max. 3 x d 1 max. 2 x d 1 max. 2 x d 1 max. 2 x d 1 max. 2 x d 1 max. 3 x d 1 max. 3 x d 1
Tech. Info
Gewindetiefe und Lochform
Thread depth and hole type
1) 1)
P 1.1- 4.1 P 1.1- 4.1 P 1.1- 4.1 P 1.1- 4.1 K 1.1- 4.2 K 1.1- 4.2 K 1.1- 4.2 K 1.1- 4.2 P 1.1- 4.1 P 1.1- 4.1 P 2.1- 4.1 P 2.1- 4.1
M 1.1- 3.1 M 1.1- 2.1 M 1.1- 3.1 M 1.1- 2.1 N 1.4-6 N 1.4-6 N 1.4-6 N 1.4-6 K 2.1-2 K 2.1-2
Einsatzgebiete – Material N 1.4-6 N 2.1 N 1.4-6 N 2.1 N 1.4-6 N 1.4-6
Applications – material  22
N 2.1-2, 2.4-5 N 2.1-2, 2.4-5
S 1.1 S 1.1
Werkzeug-Ident · Tool ident C0513720 C0653501 C0653701 C0653540 C3159401 C3179401 C3169401 C3189401 C3208F01 C3258F01 C3600F01 C3650F01
Enorm Enorm Enorm Enorm Rekord Rekord Rekord Rekord Rekord Rekord Enorm Enorm
Dimens.- 2-Z/E 2-Z50 2-Z50 2-Z50 2A-SPEED 2A-SPEED 2A-SPEED/E 2A-SPEED/E 2B-Z-SPEED 2B-Z-SPEED 2-Z-SPEED 2-Z-SPEED
ø d 1 P Ident TIN TIN IKZ-TICN IKZN-TICN IKZ-TICN IKZN-TICN PM-TIN-70 IKZN-PM X-PM X-IKZ-PM
mm mm l 1 l 2 ø d 2 „6G“ „+0,1“ TIN-70 TIN-60 TIN-60
M 3 0,5 56 6 2,2 – 2,5 .0030 M 3
4 0,7 63 7 2,8 2,1 3,3 .0040 4
5 0,8 70 8 3,5 2,7 4,2 .0050 5
6 1 80 10 4,5 3,4 5 .0060 6
7 1 80 10 5,5 4,3 6 .0070 7
8 1,25 90 14 6 4,9 6,8 .0080 8
9 1,25 90 14 7 5,5 7,8 .0090 9
10 1,5 100 16 7 5,5 8,5 .0100 10
11 1,5 100 18 8 6,2 9,5 .0111 11
12 1,75 110 18 9 7 10,2 .0112 12
14 2 110 20 11 9 12 .0114 14
16 2 110 22 12 9 14 .0116 16
18 2,5 125 25 14 11 15,5 .0118 18
20 2,5 140 25 16 12 17,5 .0120 20
22 2,5 140 27 18 14,5 19,5 .0122 22
24 3 160 30 18 14,5 21 .0124 24
27 3 160 30 20 16 24 .0127 27
30 3,5 180 35 22 18 26,5 .0130 30
33 3,5 180 35 25 20 29,5 .0133 33
36 4 200 40 28 22 32 .0136 36
39 4 200 40 32 24 35 .0139 39
42 4,5 200 45 32 24 37,5 .0142 42
45 4,5 220 45 36 29 40,5 .0145 45
48 5 250 50 36 29 43 .0148 48
52 5 250 50 40 32 47 .0152 52
DIN 371  59  59  59  59  60  60  60  60  61  61  61  61
DIN 352
2) Vorbohrdurchmesser für Gewindebohrer mit Übermaß um 0,1 mm anheben
Increase drill diameter for taps with oversize by 0.1 mm

82 Bestell-Beispiel · Ordering example: C0513720.0112
