P. 663

Spannzangen-Aufnahmen ·   Collet Holders
                                                                                                                 Product
                                                                                 Softsynchro               ®       Finder
                                                                                                                    Soft-
                                                                                               DIN 69893 A       synchro
                                                                                                                  Speed-
                                                                                                                 synchro
                                                                                                                    KSN
                                                                                                                    MQL
                                                                                                IKZ     MMS        MMS
                                                                                                         MQL
                                                                                                                    SFM
                                                                                                 pmax    pmax
                                                                                                 50bar   6bar    SWITCH-
                                                                                                                 MASTER
                                                                                                 (700psi)     (85psi)
                                     Druck C  T  Zug                                                              GR, GR-S
        Mit Bohrung für Datenträger DIN 69873  Compression  Tension                                 F
        With bore for data chip according to DIN 69873
                                                                                        C   T                        HF
                                                                                         Soft
                              ø D             ø D 1                                                                  EM
         ø D 2  G                               ø D 3                                                            Zubehör
                                                                                                                   Accessories
                                           L 4                                                                   Tech. Info
                                      E                                    Einsatz auf Maschinen   For use on machines
                                                                           mit Synchronspindel  with synchronous spindle
                  L 2          L 1

           Typ                                                  L  1  L  1                         Artikel-Nr.
          Type             ø D  1                ø D  2  ø D  ø D  3  ER  ER-GB  L  2  L  4  G  C  T     Article no.
                                               HSK-A40  34  16  89,2  87,5  20  0,9 M12 x 1  0,5  0,5  F3150C02.1
                                               HSK-A50  34  16  93,2  91,5  25  0,9 M16 x 1  0,5  0,5  F3150C03.1
       Softsynchro ®  M2 - M8  2,5 - 7  ER 11 (GB)  Hi-Q/ERM  HSK-A63  34  16  95,2  93,5  32  0,9 M18 x 1  0,5  0,5
           0     (Nr.2 -  5 /16)          11                                                      F3150C04.1
                                               HSK-A80  34  16  99,7  98  40  0,9 M20 x 1,5  0,5  0,5  F3150C05.1
                                               HSK-A100  34  16  101,7 100  50  0,9 M24 x 1,5  0,5  0,5  F3150C06.1
                                               HSK-A40  34  34  –   89,5  20  5  M12 x 1  0,5  0,5  F3151C02.1
                                               HSK-A50  34  34  –   93,5  25  5  M16 x 1  0,5  0,5  F3151C03.1
       Softsynchro ®  M4 - M12  4,5 - 10 ER 20 (GB)  Hi-Q/ERC  HSK-A63  34  34  –  95,5  32  5  M18 x 1  0,5  0,5  F3151C04.1
           1     (Nr.8 -  7 /16)          20
                                               HSK-A80  34  34  –  100   40  5  M20 x 1,5  0,5  0,5  F3151C05.1
                                               HSK-A100  34  34  –  102  50  5  M24 x 1,5  0,5  0,5  F3151C06.1
                                               HSK-A50  45  50  –  116,3  25  5  M16 x 1  0,5  0,5  F3153C03.1
       Softsynchro ®  M4 - M20          Hi-Q/ERC  HSK-A63  45  50  –  108,8  32  5  M18 x 1  0,5  0,5  F3153C04.1
           3      (Nr.8 -  3 /4)  4,5 - 16 ER 32 (GB)  32  HSK-A80  45  50  –  113,3  40  5  M20 x 1,5  0,5  0,5  F3153C05.1
                                               HSK-A100  45  50  –  115,3  50  5  M24 x 1,5  0,5  0,5  F3153C06.1
                                               HSK-A63  63  63  –  146,5  32  5  M18 x 1  0,7  0,7  F3154C04.1
       Softsynchro ®  M12 - M30  9 - 22  ER 40 (GB)  Hi-Q/ERC  HSK-A80  63  63  –  136  40  5  M20 x 1,5  0,7  0,7
           4     ( 7 /16 - 1  1 /8)       40                                                      F3154C05.1
                                               HSK-A100  63  63  –  138  50  5  M24 x 1,5  0,7  0,7  F3154C06.1
       1)   Einstecktiefen E siehe Seite 797                                                 Weitere Ausführungen auf Anfrage
          Clamping depths E, see page 797                                                  Further designs upon request
       Softsynchro ®  0                                     Softsynchro ®  1-4
         Spannmutter ohne integrierte Abdichtung ist im Lieferumfang enthalten     Spannmutter für Dichtscheiben ist im Lieferumfang enthalten
         Clamping nut without integrated seal is included in the delivery    Clamping nut for sealing disks is included in the delivery


        Zubehör
       Accessories

                Spannzangen Typ ER (GB)
                  Collets type ER (GB)   786 - 787                           Spannschlüsselsatz
                                                                                                      793
                                                                               Set of clamping wrenches
                Dichtscheiben Typ DS/ER
                  Sealing disks type DS/ER   789

                                                                                Montagevorrichtung
                Spannmutter mit integrierter                                     Assembly device      793
                Abdichtung Typ Hi-Q/ERMC 11    790
                Clamping nut with integrated seal,
                type Hi-Q/ERMC 11
                                                                                 Kühlschmierstoffrohre und Schlüssel    782 - 783
                                                                                 Coolant tubes and wrenches

                                                                                Drehmomentschlüssel TORCO-FIX
                                                                                Torque wrenches TORCO-FIX   795


         = Lagerwerkzeug, siehe Preisliste  · Stock tool, see price list                                    663
         = Kurzfristig lieferbar, Preis auf Anfrage  · Available on short notice, price upon inquiry
