Page 158 - EMUGE

Maschinen-Gewindebohrer · Machine Taps Enorm 2
Product Z
Finder 60° ≈ DIN CNC-controlled
UNF
P
machines
v c 374
M new new new new
ASME B1.1
MF
UNC
UN-8
UNF
UNEF
G, Rp
NPSM, NPSF
NPT, NPTF l 1
Rc, W
l 2
BSW, BSF
ø d 1 ø d 2
Pg
MJ Toleranz · Tolerance
UNJC, UNJF 2BX 2BX 2BX 2BX
Beschichtung · Coating TIN-60 GLT-1 TIN-60 GLT-1
EG (STI)
SELF-LOCK Technische Informationen Schneidstoff · Cutting material HSSE-PM HSSE-PM HSSE-PM HSSE-PM
Tr, Tr-F Technical information  245 - 266 R45 R45 R45 R45
Rd
C / 2-3 C / 2-3 E / 1,5-2 E / 1,5-2
Zubehör E / O / P E / O / P E / O / P E / O / P
Accessories
max. 3 x d 1
Tech. Info
Gewindetiefe und Lochform
Thread depth and hole type
P 2.1- 4.1 P 2.1- 4.1 P 2.1- 4.1 P 2.1- 4.1
M 1.1- 3.1 M 1.1- 3.1 M 1.1- 3.1 M 1.1- 3.1
Einsatzgebiete – Material K 2.1 K 2.1 K 2.1 K 2.1
Applications – material  22
N 1.4- 2.2, 2.4-5 N 1.4- 2.2, 2.4-5 N 1.4- 2.2, 2.4-5 N 1.4- 2.2, 2.4-5
S 1.1 S 1.1 S 1.1 S 1.1
Werkzeug-Ident · Tool ident C5760F01 C576A601 C5820F01 C582A601
Enorm Enorm Enorm Enorm
Dimens.- 2-Z-X-PM 2-Z-X-PM 2-Z/E-X-PM 2-Z/E-X-PM
ø d 1 P Ident TIN-60 GLT-1 TIN-60 GLT-1
inch inch Gg/1" (tpi) l 1 l 2 ø d 2
1 /4 0.2500 28 80 10 4,5 3,4 5,5 .5043
5 /16 0.3125 24 90 10 6 4,9 6,9 .5044
3 /8 0.3750 24 90 10 7 5,5 8,5 .5045
7 /16 0.4375 20 100 13 8 6,2 9,9 .5046
1 /2 0.5000 20 100 13 9 7 11,5 .5047
9 /16 0.5625 18 100 15 11 9 12,9 .5048
5 /8 0.6250 18 100 15 12 9 14,5 .5049
3 /4 0.7500 16 110 17 14 11 17,5 .5050
7 /8 0.8750 14 125 17 18 14,5 20,4 .5051
1" 1.0000 12 140 20 18 14,5 23,25 .5052
1 1 /8 1.1250 12 150 22 22 18 26,5 .5053
1 1 /4 1.2500 12 150 22 22 18 29,5 .5054
1 3 /8 1.3750 12 170 24 28 22 32,75 .5055
1 1 /2 1.5000 12 170 24 28 22 36 .5056
≈ DIN 371  154  154  154  154

158 Bestell-Beispiel · Ordering example: C5760F01.5046
