Chamfer dimensions
Diameter series Maximum chamfer

identification dimensions
The maximum chamfer dimensions (ig. 1)
for the radial (r , r ) and axial (r , r ) directions,
3
2
4
1
The bore and outside diameter variation appropriate to the respective minimum values
tolerances t Vdsp and t VDsp for metric radial and the bore or outside diameter, are listed
bearings (table 2, page 38, to table 4, in the following tables:
page 40) vary depending on the diameter
series to which the bearing belongs. To • Metric radial and thrust bearings, except
determine the diameter series, refer to radial tapered roller bearings
table 14, page 52. (table 15, page 53)
• Metric radial tapered roller bearings
(table 16, page 53) Tolerances
• Inch tapered roller bearings (table 17,
Chamfer page 54)

dimensions The maximum chamfer dimensions A.2
for metric SKF bearings are in accordance
with ISO 582.
Example
Minimum chamfer
dimensions What is the largest radial and axial value
) for the chamfer of a 6211
and r
(r
2 max
1 max
deep groove ball bearing?
Minimum chamfer dimensions (ig. 1) are From the relevant product table,
listed in the product tables, for the radial (r , r 1,2 min = 1,5 mm and d = 55 mm.
1
r ) and axial (r , r ) directions. For metric From table 15, with r s min = 1,5 mm and
4
2
3
SKF bearings, these values are in accordance d < 120 mm, the largest radial value
with the general plans listed in the following r 1 max = 2,3 mm and the largest axial value
standards: r 2 max = 4 mm.
• ISO 15, ISO 12043 and ISO 12044 for
radial bearings
• ISO 355 for radial tapered roller bearings
• ISO 104 for thrust bearings

Fig. 1
Minimum and maximum chamfer
dimensions

r 1 max r 3 max
r 1 min r 3 min

r 2 min
r 4 min
r 2 max
r 4 max

37
