2 Insert bearings (Y-bearings)
Assembling insert
Table 15
Grub screws in SKF ConCentra insert bearings – key sizes and recommended tightening bearings into
torques
housings with fitting

2 slots

N
When mounting an insert bearing into a
housing with itting slots, the bearing should
be inserted into the itting slot in the housing
bore (ig. 33) and then swivelled into position
The misalignment of the bearing relative to
Bearing size 1) Screw Hexagonal Tightening the housing should not exceed 5° Eccentric
size key size torque locking collars should be removed from the
≥ ≤ N
bearing prior to mounting and reinstalled
– – mm Nm when the bearing is in position in the housing
The locking device should face in the same
direction as the itting slots, except for stain-
05 06 M5 2,5 4,2
07 13 M6 3 7,4 less steel housings and composite housings
for SKF Food Line with designation sufix L
Where mounting bearings into these hous-
ings, the locking device should face in the
1) For example, bearing size 07 includes all bearings based on a 207 insert bearing, such as YSP 207 SB-2F, YSP 207-104 SB-2F, opposite direction to the itting slots
YSP 207-106 SB-2F, YSP 207-107 SB-2F
Make sure that no relubrication hole or
groove in the bearing outside diameter
Fig. 33 coincides with either of the itting slots in
Assembling a bearing into a housing with the housing, otherwise grease leakage may
itting slots result or contamination might enter the
bearing (ig. 34)
If the bearing has to be relubricated, make
sure the relubrication features in the outer
ring (hole, or groove and hole) coincide with
the relubrication feature in the housing bore
The misalignment of the bearing relative to
the housing should not exceed 2°, otherwise
relubrication will not be possible (ig. 35)
SKF recommends mounting SKF insert
bearings only into SKF housings to avoid a
mismatch of components and to enable
proper bearing relubrication
Fig. 34
Relubrication hole or groove not to coincide with itting slots
