P. 135
2.3
N
G A 1 N 1
H 2
J
L
Shaft diameter Dimensions Mass
Ho using
1) 1) A H J L N G
d a d b d c d c A 1 C a D a H 1 H 2 N 1
min max
mm mm kg
75 85 115 80 56 130 156 80 30 230 280 24 18 16 8,10
84 84
85 115 80 56 130 156 80 30 230 280 24 18 16 8,60
84 84
85 – – 140 100 65 160 194 100 35 290 345 28 22 20 12,5
80 90 – – 120 90 58 140 177 95 32 260 315 28 22 20 9,00
90 – – 120 90 58 140 177 95 32 260 315 28 22 20 9,00
90 – – 145 100 68 170 212 112 35 290 345 28 22 20 13,7
1) Valid for some sealed spherical roller bearings only.
131
