2.3
N
G A 1 N 1
H 2
J
L
Shaft diameter Dimensions Eye bolt Mass
acc. to Housing
DIN 580
1) 1) A H J L N G
d a d b d c d c A 1 C a D a H 1 H 2 N 1
min max
mm mm – kg
95 110 – – 175 120 80 200 242 125 45 350 410 32 26 24 – 22,0
100 115 160 110 70 180 218 112 40 320 380 32 26 24 – 17,6
112 114
115 – – 185 120 86 215 271 140 45 350 410 32 26 24 M 10 26,2
110 125 – – 175 120 80 200 242 125 45 350 410 32 26 24 – 22,0
120 135 – – 185 120 86 215 271 140 45 350 410 32 26 24 M 10 26,2
1) Valid for some sealed spherical roller bearings only.
