2.2

N

G A 1 N 1

H 2
J
L

Shaft Dimensions Eye bolt Mass
diameter acc. to DIN Housing
580
A H J L N G G
d a A 1 C a D a H 1 H 2 N 1
in./mm mm in. – kg
4 175 120 80 200 242 125 45 350 410 32 26 24 7 /8 – 22,0
101,6

4 3 /16 185 120 86 215 271 140 45 350 410 32 26 24 7 /8 M 10 26,2
106,363

4 1 /4 185 120 86 215 271 140 45 350 410 32 26 24 7 /8 M 10 26,2
107,95

4 7 /16 190 130 90 230 290 150 50 380 445 35 28 24 1 M 10 33,0
112,713

4 1 /2 190 130 90 230 290 150 50 380 445 35 28 24 1 M 10 33,0
114,3
