2.2

N

G A 1 N 1

H 2
J
L

Shaft Dimensions Mass
diameter Housing
A H J L N G G
d a A 1 C a D a H 1 H 2 N 1
in./mm mm in. kg

1 1 /2 85 60 30 85 109 60 25 170 205 20 15 12 1 /2 3,40
38,1

95 70 44 100 129 70 28 210 255 24 18 16 5 /8 5,45

1 11 /16 90 60 41 90 114 60 25 170 205 20 15 12 1 /2 3,85
42,863

105 70 48 110 134 70 30 210 255 24 18 16 5 /8 6,15

1 3 /4 90 60 41 90 114 60 25 170 205 20 15 12 1 /2 3,85
44,45

105 70 48 110 134 70 30 210 255 24 18 16 5 /8 6,15
