Designs and variants
Designs and Single row deep Fig. 1 1

variants groove ball bearings Single row bearing
with filling slots

Single row deep groove ball bearings with
illing slots have a illing slot in both the inner
Single row deep and outer rings (ig. 3) to accommodate

groove ball bearings more balls than standard deep groove ball
bearings
Filling slot bearings have a higher radial
Single row deep groove ball bearings (ig. 1) load carrying capacity than bearings without
are available capped (with seals or shields) illing slots, but their axial load carrying
or open. Open bearings that are also avail- capacity is limited They are also unable to
able capped may have recesses in the ring operate at the same high speeds as bearings
side faces (ig. 2). without illing slots Fig. 2
SKF inch bearings in the EE(B), RLS and Deep groove ball bearings with illing slots Open designs
RMS series are intended as aftermarket are available open or with shields on one or
items and, therefore, SKF recommends not both sides They are also available with or
using these bearings for new bearing without a snap ring groove Open bearings
arrangement designs (skf.com/go/17000-1-1). that are also available with shields may have
SKF can also supply bearings with a recesses in the outer ring (ig. 4)
tapered bore. For detailed information, Large size deep groove ball bearings with
contact SKF. illing slots, without cage, are available on
request

Stainless steel deep
groove ball bearings

Fig. 3
Stainless steel deep groove ball bearings Bearing with illing slots
(ig. 1) are available capped (with seals or
shields) or open. Open bearings that are also
available capped may have recesses in the
ring side faces (ig. 2).
These bearings have a lower load carrying
capacity than same-sized bearings made of
high chromium steel.
Inch stainless steel deep groove ball bear-
ings are not listed in this catalogue, but can
be found online at skf.com/go/17000-1-4

Fig. 4
Open designs of bearings with illing slots
