Mechanically operated pumps

Features and benefits
Virtually maintenance-free, vibration-proof, 24/7 design, Designed for high ambient temperatures and all standard lubrication oils, Machine operated; no under- or over-lubrication, Oil supply from machine sump or from existing oil-circulation system, Adjustable output, Available for two drive directions

Applications
Marine industry; inlet valve seat lubrication for powerful four-stroke engines, General machine-driven applications

Features and benefits
Modular pump-to-point solution for 1 to 20 lubrication points, Depending on drive speed respective of selected drive ratio, RA pumps cover feed rates of some droplets until 36 cm3 / min (2.2 in3 / min), Drive direction left or right, Compatible with mineral- and synthetic-based oil, Vibration-proof, marine and ATEX versions available, Supplies several different lubrication zones, lubrication points or chain pins

Applications
Gas compressors and large pumps, Economic power unit for sealing oil systems, Marine, valve-seat lubrication on large four-stroke engines

Features and benefits
Easy adjustment of flow rate, Pushbutton for pre-lubrication and system de-aeration, Modular box lubricator mounting for ease of maintenance, Pumps with suction tube for oil suction from the lubricator box or with direct feed by overhead reservoir, With or without sight glass for visual flow indication, For operating viscosity up to 1 700 mm2/s

Applications
Gas engines, Reciprocating compressors, High-pressure oil, total-loss lubrication systems

Features and benefits
Designed for 24/7 operation, Three piston sizes cover output from 0,17 to 5,0 cm3/min (0.01 to 0.29 in3/min) per outlet, Individual outlet settings between 25 and 100%, Pressure-tight design available, Can be monitored according to API 618 standards, Most reliable replacement for all standard box lubricators

Applications
Reciprocating gas compressors, mainly in an ATEX environment, Pump-to-point lubrication of packings and cylinders, Petro-chemical and food and beverage industry

Features and benefits
Designed for continuous 24/7 operation, Modular pump design enables use of up to five pumping elements, Pressure-tight design; suitable for overhead reservoir connection, Rack arrangement with additional pumps, filter and flow control equipment available

Applications
Petro-chemical industry

Features and benefits
Accurate, timed oil metering quantities within a millisecond, Load-dependent, lubrication standard, Modular design for easy assembly and service, Prevents over-lubrication, deposits,
excess smoke and CO2, Provides up to 40% oil savings, Retrofit solutions available

Applications
Marine industry, General industry, Chains or compressors
