ชื่อรุ่น :
SPC/22
แบรนด์
Optibelt
รายละเอียด :
optibelt KS ( SPC ) มู่เล่ย์ ร่องวี สำหรับรูล็อคทรงกระบอกแบบมาตราฐาน สูงสุด 85 มม.
- ขนาดเส้นผ่าศูนย์กลางของมู่เล่ย์ มีตั้งแต่ 180 - 630 มม.
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
SPC 180
Model description
Datum diameter = 180.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 40.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 64.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 200
Model description
Datum diameter = 200.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 40.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 64.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 125.0 mm
Price
Model
SPC 225
Model description
Datum diameter = 225.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 64.0 mm
3 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 250
Model description
Datum diameter = 250.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 64.0 mm
3 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 280
Model description
Datum diameter = 280.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 64.0 mm
3 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 100.0 mm
Price
Model
SPC 315
Model description
Datum diameter = 315.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 52.0 mm ,Hub length l = 54.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 74.0 mm
3 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 85.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 335
Model description
Datum diameter = 335.00 mm
No. of grooves : 2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 74.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 355
Model description
Datum diameter = 355.00 mm
No. of grooves : 2 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 74.0 mm
3 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 95.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 100.0 mm
6 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 115.0 mm
Price
Model
SPC 400
Model description
Datum diameter = 400.00 mm
No. of grooves : 3 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 105.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 100.0 mm
Price
Model
SPC 450
Model description
Datum diameter = 450.00 mm
No. of grooves : 2 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 80.0 mm
3 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 105.0 mm
5 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 110.0 mm
6 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 120.0 mm
Price
Model
SPC 500
Model description
Datum diameter = 500.00 mm
No. of grooves : 3 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 105.0 mm
5 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 110.0 mm
6 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 120.0 mm
Price
Model
SPC 560
Model description
Datum diameter = 560.00 mm
No. of grooves : 3 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 105.0 mm
5 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 110.0 mm
6 groove , Finished bore hole dmax. = 85.0 mm ,Hub length l = 120.0 mm
Price
Model
SPC 630
Model description
Datum diameter = 630.00 mm
No. of grooves : 3 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 90.0 mm
4 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 105.0 mm
5 groove , Finished bore hole dmax. = 85.0 mm ,Hub length l = 110.0 mm
6 groove , Finished bore hole dmax. = 85.0 mm ,Hub length l = 120.0 mm
