PRODUCT
![]()
ชื่อรุ่น :
TB SPZ/10
แบรนด์
Optibelt
รายละเอียด :
optibelt KS ( SPZ ) มู่เล่ย์ ร่องวี สำหรับล็อคด้วยเทเปอร์บู๊ธ
- ขนาดเส้นผ่าศูนย์กลางของมู่เล่ย์ มีตั้งแต่ 50 - 630 มม.
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
TB SPZ 50
Model description
Datum diameter = 50.00 mm
No. of grooves : 1 groove , Taper bushing No. 1008
2 groove , Taper bushing No. 1008
Price
Model
TB SPZ 56
Model description
Datum diameter = 56.00 mm
No. of grooves : 1 groove , Taper bushing No. 1008
2 groove , Taper bushing No. 1108
Price
Model
TB SPZ 60
Model description
Datum diameter = 60.00 mm
No. of grooves : 1 groove , Taper bushing No. 1008
2 groove , Taper bushing No. 1108
Price
Model
TB SPZ 63
Model description
Datum diameter = 63.00 mm
No. of grooves : 1 groove , Taper bushing No. 1108
2 groove , Taper bushing No. 1108
3 groove , Taper bushing No. 1108
Price
Model
TB SPZ 67
Model description
Datum diameter = 67.00 mm
No. of grooves : 1 groove , Taper bushing No. 1108
2 groove , Taper bushing No. 1108
3 groove , Taper bushing No. 1108
Price
Model
TB SPZ 71
Model description
Datum diameter = 71.00 mm
No. of grooves : 1 groove , Taper bushing No. 1108
2 groove , Taper bushing No. 1108
3 groove , Taper bushing No. 1108
Price
Model
TB SPZ 75
Model description
Datum diameter = 75.00 mm
No. of grooves : 1 groove , Taper bushing No. 1108
2 groove , Taper bushing No. 1210
3 groove , Taper bushing No. 1210
Price
Model
TB SPZ 80
Model description
Datum diameter = 80.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1210
3 groove , Taper bushing No. 1210
4 groove , Taper bushing No. 1210
Price
Model
TB SPZ 85
Model description
Datum diameter = 85.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 1610
4 groove , Taper bushing No. 1610
5 groove , Taper bushing No. 1610
Price
Model
TB SPZ 90
Model description
Datum diameter = 90.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 1610
4 groove , Taper bushing No. 1610
5 groove , Taper bushing No. 1610
Price
Model
TB SPZ 95
Model description
Datum diameter = 95.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 1610
4 groove , Taper bushing No. 1610
5 groove , Taper bushing No. 1610
Price
Model
TB SPZ 100
Model description
Datum diameter = 100.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 1610
4 groove , Taper bushing No. 1610
5 groove , Taper bushing No. 2012
6 groove , Taper bushing No. 2012
Price
Model
TB SPZ 106
Model description
Datum diameter = 106.00 mm
No. of grooves : 1 groove , Taper bushing No. 1210
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 1610
4 groove , Taper bushing No. 1610
5 groove , Taper bushing No. 2012
6 groove , Taper bushing No. 2012
Price
Model
TB SPZ 112
Model description
Datum diameter = 112.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2012
5 groove , Taper bushing No. 2012
6 groove , Taper bushing No. 2012
Price
Model
TB SPZ 118
Model description
Datum diameter = 118.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2012
5 groove , Taper bushing No. 2012
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 125
Model description
Datum diameter = 125.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2012
5 groove , Taper bushing No. 2012
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 132
Model description
Datum diameter = 132.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2012
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 140
Model description
Datum diameter = 140.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 1610
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2012
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 2517
Price
Model
TB SPZ 150
Model description
Datum diameter = 150.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 2517
Price
Model
TB SPZ 160
Model description
Datum diameter = 160.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 2517
Price
Model
TB SPZ 170
Model description
Datum diameter = 170.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 180
Model description
Datum diameter = 180.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 2517
Price
Model
TB SPZ 190
Model description
Datum diameter = 190.00 mm
No. of grooves : 1 groove , Taper bushing No. 1610
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 200
Model description
Datum diameter = 200.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 3020
Price
Model
TB SPZ 224
Model description
Datum diameter = 224.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 3020
Price
Model
TB SPZ 250
Model description
Datum diameter = 250.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2012
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 3020
Price
Model
TB SPZ 280
Model description
Datum diameter = 280.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 3020
Price
Model
TB SPZ 315
Model description
Datum diameter = 315.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
Price
Model
TB SPZ 355
Model description
Datum diameter = 355.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2012
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 2517
6 groove , Taper bushing No. 2517
8 groove , Taper bushing No. 3030
Price
Model
TB SPZ 400
Model description
Datum diameter = 400.00 mm
No. of grooves : 1 groove , Taper bushing No. 2012
2 groove , Taper bushing No. 2517
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 2517
5 groove , Taper bushing No. 3020
6 groove , Taper bushing No. 3030
8 groove , Taper bushing No. 3030
Price
Model
TB SPZ 450
Model description
Datum diameter = 450.00 mm
No. of grooves : 1 groove , Taper bushing No. 2517
2 groove , Taper bushing No. 2517
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 3020
5 groove , Taper bushing No. 3020
6 groove , Taper bushing No. 3030
8 groove , Taper bushing No. 3535
Price
Model
TB SPZ 500
Model description
Datum diameter = 500.00 mm
No. of grooves : 2 groove , Taper bushing No. 2517
3 groove , Taper bushing No. 2517
4 groove , Taper bushing No. 3020
5 groove , Taper bushing No. 3030
6 groove , Taper bushing No. 3030
Price
Model
TB SPZ 630
Model description
Datum diameter = 630.00 mm
No. of grooves : 3 groove , Taper bushing No. 3020
4 groove , Taper bushing No. 3030
5 groove , Taper bushing No. 3030
6 groove , Taper bushing No. 3535
Price
